VRL 090 Frame

The VRL Series is the all-rounder in the planetary gear reducer marketplace. With helical gearing, robust internal construction, smooth operation and high torque density, the VRL is truly best-in-class. 5 arc-min backlash allows the VRL to be applied to a wide range of applications where accuracy and dynamics are in play, but cost is of concern.

Downloads

Selection Configurator

VRL 090 Series Catalog

Installation Manual

Technical Data

VRL 090 Frame Size, 1 Stage Specifications

RatioUnitsNote345678910
Nominal Output Torque[Nm]*15377848484848484
Maximum Acceleration Torque[Nm]*2108165165165165165112112
Maximum Torque[Nm]*3135200200195195190145145
Emergency Stop Torque[Nm]*4200250250250250250200200
Nominal Input Speed[rpm]*529002900290029003100310031003100
Maximum Input Speed[rpm]*675007500750075007500750075007500
No Load Running Torque[Nm]*70.350.350.350.350.350.350.350.35
Maximum Radial Load[N]*824002400240024002400240024002400
Maximum Axial Load[N]*922002200220022002200220022002200
Moment of Inertia (≤Ø 8)[kgcm2]–––––––––
Moment of Inertia (≤ Ø 14)[kgcm2]–0.720.500.410.360.330.310.300.30
Moment of Inertia (≤ Ø 19)[kgcm2]–1.10.900.800.750.730.710.700.70
Moment of Inertia (≤ Ø 28)[kgcm2]–2.92.72.62.52.52.52.52.5
Efficiency[%]*109595959595959595
Torsional Rigidity[Nm/arc-min]*111010101010101010
Maximum Torsional Backlash[arc-min]–≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5
Noise LeveldB [A]*12≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67
Protection Class–*13IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)
Ambient Temperature[°C]–0-400-400-400-400-400-400-400-40
Permitted Housing Temperature[°C]–9090909090909090
Weight[kg]*143.53.53.53.53.53.53.53.5

VRL 090 Frame Size, 2 Stage Specifications

RatioUnitsNote1516202528303540
Nominal Output Torque[Nm]* 165808610611888118118
Maximum Acceleration Torque[Nm]*2108165165165165108165165
Maximum Torque[Nm]*3108165165165165108165165
Emergency Stop Torque[Nm]*4200250250250250200250250
Nominal Input Speed[rpm]*535003500350035003500350035003500
Maximum Input Speed[rpm]*685008500850085008500850085008500
No Load Running Torque[Nm]*70.060.060.060.060.060.060.060.06
Maximum Radial Load[N]*824002400240024002400240024002400
Maximum Axial Load[N]*922002200220022002200220022002200
Moment of Inertia (≤Ø 8)[kgcm2]–0.200.250.190.190.240.120.180.11
Moment of Inertia (≤ Ø 14)[kgcm2]–0.360.410.350.350.400.280.350.28
Moment of Inertia (≤ Ø 19)[kgcm2]–0.750.790.740.740.780.670.730.67
Moment of Inertia (≤ Ø 28)[kgcm2]–2.52.52.52.52.52.42.52.4
Efficiency[%]*109090909090909090
Torsional Rigidity[Nm/arc-min]*111010101010101010
Maximum Torsional Backlash[arc-min]–≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5
Noise LeveldB [A]*12≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67
Protection Class–*13IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)
Ambient Temperature[°C]–0-400-400-400-400-400-400-400-40
Permitted Housing Temperature[°C]–9090909090909090
Weight[kg]*1444444444
RatioUnitsNote455060708090100
Nominal Output Torque[Nm]* 1881181181181188888
Maximum Acceleration Torque[Nm]*2112165165165165112112
Maximum Torque[Nm]*3112165165165165112112
Emergency Stop Torque[Nm]*4200250250250250200200
Nominal Input Speed[rpm]*53500380038004500450045004500
Maximum Input Speed[rpm]*68500850085008500850085008500
No Load Running Torque[Nm]*70.060.060.060.060.060.060.06
Maximum Radial Load[N]*82400240024002400240024002400
Maximum Axial Load[N]*92200220022002200220022002200
Moment of Inertia (≤Ø 8)[kgcm2]–0.180.110.110.110.110.110.11
Moment of Inertia (≤ Ø 14)[kgcm2]–0.340.270.270.270.270.270.27
Moment of Inertia (≤ Ø 19)[kgcm2]–0.730.670.670.670.670.670.67
Moment of Inertia (≤ Ø 28)[kgcm2]–2.52.42.42.42.42.42.4
Efficiency[%]*1090909090909090
Torsional Rigidity[Nm/arc-min]*1110101010101010
Maximum Torsional Backlash[arc-min]–≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5≤ 5
Noise LeveldB [A]*12≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67≤ 67
Protection Class–*13IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)IP54 (IP65)
Ambient Temperature[°C]–0-400-400-400-400-400-400-40
Permitted Housing Temperature[°C]–90909090909090
Weight[kg]*144444444
  1. At nominal input speed, service life is 20,000 hours
  2. The maximum torque when starting or stopping operation. Apply Cycle Factor f0 on Selection Flow Charts, for higher duty cycle applications
  3. Permitted 10,000 times during service life. Based on 10% of maximum radial load and smooth output shaft
  4. The maximum torque allowed under a stress situation. Permitted 1,000 times during service life
  5. The average input speed at nominal input torque. Maintain housing temperature below permitted value
  6. The maximum intermittent input speed
  7. Torque at no load applied to the input shaft at nominal input speed
  8. The maximum radial load that the gearbox can accept
  9. The maximum axial load that the gearbox can accept
  10. The efficiency at the nominal output torque rating
  11. This does not include lost motion
  12. Contact Nidec Drive Technology Corporation for the testing conditions and environment
  13. IP65 (wash-down) is available as an option. Contact Nidec Drive Technology Corporation for more details
  14. Weight may vary slightly between models
