EVL 205 Frame

The right angle equivalent to the VRL series, the EVL provides our customers with an excellent solution when space and clearance are a serious limitation. Helical planetary gears team up with spiral bevel gears to provide a product with robust internal construction, smooth operation and high torque density. 6 arc-min backlash allows the VRL to be applied to a wide range of applications where accuracy and dynamics are in play, but cost is of concern.

Downloads

Selection Configurator

EVL 205 Frame

Installation Manual

Technical Data

EVL 205 Frame Size, 2 Stage Specifications

Ratio	Units	Note	3	4	5	6	7	8	9	10
Nominal Output Torque	[Nm]	*1	421	604	646	646	646	646	478	478
Maximum Acceleration Torque	[Nm]	*2	679	904	1127	1315	1315	1315	931	931
Maximum Torque	[Nm]	*3	750	1064	1327	1498	1498	1498	1144	1144
Emergency Stop Torque	[Nm]	*4	1300	1700	2000	2500	2500	2500	2000	2000
Nominal Input Speed	[rpm]	*5	1500	1500	1500	1500	1500	1500	1500	1500
Maximum Input Speed	[rpm]	*6	4000	4000	4000	4000	4000	4000	4000	4000
No Load Running Torque	[Nm]	*7	10.8	10.8	10.8	10.8	10.8	10.8	10.8	10.8
Maximum Radial Load	[N]	*8	15000	15000	15000	15000	15000	15000	15000	15000
Maximum Axial Load	[N]	*9	14000	14000	14000	14000	14000	14000	14000	14000
Moment of Inertia (≤Ø 28)	[kgcm2]	–	–	–	–	–	–	–	–	–
Moment of Inertia (≤ Ø 38)	[kgcm2]	–	93.71	77.72	71.89	68.74	66.43	65.27	64.60	64.28
Moment of Inertia (≤ Ø 48)	[kgcm2]	–	128.6	112.6	106.8	103.6	101.3	100.1	99.46	99.14
Moment of Inertia (≤ Ø 65)	[kgcm2]	–	214.2	198.2	192.4	189.2	186.9	185.7	185.1	184.7
Efficiency	[%]	*10	93	93	93	93	93	93	93	93
Torsional Rigidity	[Nm/arc-min]	*11	175	175	175	175	175	175	175	175
Maximum Torsional Backlash	[arc-min]	–	≤ 8	≤ 8	≤ 8	≤ 8	≤ 8	≤ 8	≤ 8	≤ 8
Noise Level	dB [A]	*12	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85
Protection Class	–	*13	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)
Ambient Temperature	[°C]	–	0-40	0-40	0-40	0-40	0-40	0-40	0-40	0-40
Permitted Housing Temperature	[°C]	–	90	90	90	90	90	90	90	90
Weight	[kg]	*14	52	52	52	52	52	52	52	52

EVL 205 Frame Size, 3 Stage Specifications

Ratio	Units	Note	15	16	20	25	28	30	35	40
Nominal Output Torque	[Nm]	* 1	442	583	646	683	710	480	710	465
Maximum Acceleration Torque	[Nm]	*2	916	1315	1315	1315	1315	916	1315	1315
Maximum Torque	[Nm]	*3	916	1315	1315	1315	1315	916	1315	1315
Emergency Stop Torque	[Nm]	*4	2000	2500	2500	2500	2500	2000	2500	2500
Nominal Input Speed	[rpm]	*5	2100	2100	2100	2100	2100	2100	2100	2100
Maximum Input Speed	[rpm]	*6	4000	4000	4000	4000	4000	4000	4000	4000
No Load Running Torque	[Nm]	*7	4.7	4.7	4.7	4.7	4.7	4.7	4.7	4.7
Maximum Radial Load	[N]	*8	15000	9100	9100	9100	9100	9100	9100	9100
Maximum Axial Load	[N]	*9	14000	8200	8200	8200	8200	8200	8200	8200
Moment of Inertia (≤Ø 28)	[kgcm2]	—	11.49	12.09	11.15	10.98	11.59	10.33	10.83	10.24
Moment of Inertia (≤ Ø 38)	[kgcm2]	—	20.28	20.88	19.94	19.77	20.38	19.11	19.62	19.03
Moment of Inertia (≤ Ø 48)	[kgcm2]	—	25.10	25.70	24.76	24.59	25.20	23.94	24.44	23.85
Moment of Inertia (≤ Ø 65)	[kgcm2]	–	–	–	–	–	–	–	–	–
Efficiency	[%]	*10	88	88	88	88	88	88	88	88
Torsional Rigidity	[Nm/arc-min]	*11	175	175	175	175	175	175	175	175
Maximum Torsional Backlash	[arc-min]	–	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11
Noise Level	dB [A]	*12	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85
Protection Class	–	*13	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)
Ambient Temperature	[°C]	–	0-40	0-40	0-40	0-40	0-40	0-40	0-40	0-40
Permitted Housing Temperature	[°C]	–	90	90	90	90	90	90	90	90
Weight	[kg]	*14	39	39	39	39	39	39	39	39

Ratio	Units	Note	45	50	60	70	80	90	100
Nominal Output Torque	[Nm]	* 1	480	710	710	710	710	480	480
Maximum Acceleration Torque	[Nm]	*2	931	1315	1315	1315	1315	931	931
Maximum Torque	[Nm]	*3	931	1315	1315	1315	1315	931	931
Emergency Stop Torque	[Nm]	*4	2000	2500	2500	2500	2500	2000	2000
Nominal Input Speed	[rpm]	*5	2100	2100	2100	2100	2100	2100	2100
Maximum Input Speed	[rpm]	*6	4000	4000	4000	4000	4000	4000	4000
No Load Running Torque	[Nm]	*7	4.7	4.7	4.7	4.7	4.7	4.7	4.7
Maximum Radial Load	[N]	*8	15000	15000	15000	15000	15000	15000	15000
Maximum Axial Load	[N]	*9	14000	14000	14000	14000	14000	14000	14000
Moment of Inertia (≤Ø 28)	[kgcm2]	–	10.76	10.20	10.18	10.16	10.15	10.15	10.14
Moment of Inertia (≤ Ø 38)	[kgcm2]	–	19.55	18.99	18.96	18.95	18.94	18.93	18.93
Moment of Inertia (≤ Ø 48)	[kgcm2]	–	24.37	23.81	23.78	23.77	23.76	23.75	23.75
Moment of Inertia (≤ Ø 65)	[kgcm2]	–	–	–	–	–	–	–	–
Efficiency	[%]	*10	88	88	88	88	88	88	88
Torsional Rigidity	[Nm/arc-min]	*11	175	175	175	175	175	175	175
Maximum Torsional Backlash	[arc-min]	–	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11	≤ 11
Noise Level	dB [A]	*12	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85	≤ 85
Protection Class	–	*13	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)	IP54 (IP65)
Ambient Temperature	[°C]	–	0-40	0-40	0-40	0-40	0-40	0-40	0-40
Permitted Housing Temperature	[°C]	–	90	90	90	90	90	90	90
Weight	[kg]	*14	39	39	39	39	39	39	39

At nominal input speed, service life is 20,000 hours
The maximum torque when starting or stopping operation. Apply Cycle Factor f₀ on Selection Flow Charts, for higher duty cycle applications
Permitted 10,000 times during service life. Based on 10% of maximum radial load and smooth output shaft
The maximum torque allowed under a stress situation. Permitted 1,000 times during service life
The average input speed at nominal input torque. Maintain housing temperature below permitted value
The maximum intermittent input speed
Torque at no load applied to the input shaft at nominal input speed
The maximum radial load that the gearbox can accept
The maximum axial load that the gearbox can accept
The efficiency at the nominal output torque rating
This does not include lost motion
Contact Nidec Drive Technology Corporation for the testing conditions and environment
Various wash-down options are available. Contact Nidec Drive Technology for more details
Weight may vary slightly between models

EVL 205 2 Stage Dimensions

EVL 205 3 Stage Dimensions

Motor Mounting Codes

Our motor mounting codes can be configured automatically using our online selection tool. These tables supply the details behind these codes. The tables start with Input Bore measurement and the Part # Code, which are indicated at the end of every model code.
For each Part # Code, the Pilot, BCD, Tapped Hole, and Pilot Depth, are explained.

Please note that even though the Part# Code may have the same letters (i.e. DC, FB, HA, etc.), the Pilot and BCD dimensions may not be the same if a different input bore diameter. Locate the table by input bore diameter first, and then find the appropriate adapter Part# Code to check the dimensions. If you have any questions, contact Nidec Drive Technology for support.

65, 48, and 38 Input Bore Mounting Code Tables

Input Bore (mm)	Part # Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
65	MA	114.3	200	M12	8
65	MB	200	235	M12	8
65	MC	180	215	M12	8
65	MD	180	265	M12	8
65	NA	230	265	M12	8
65	NB	230	265	M12	18
65	NC	230	290	M12	8
65	ND	230	265	M20	18
65	PA	250	300	M16	8
65	PB	250	320	M16	18
65	QA	300	350	M16	8
65	QB	280	325	M16	8

Input Bore (mm)	Part # Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
48	KA	114.3	200	M12	8
48	KB	110	130	8.8	8
48	KC	130	215	M12	8
48	LA	180	215	M12	8
48	MA	180	265	M12	8
48	MB	200	235	M12	8
48	NA	230	265	M12	8
48	PA	250	300	M16	8

Input Bore (mm)	Part # Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
38	HA	110	130	8.8	8
38	HB	110	145	M8	8
38	HE	110	130	M8	8
38	JA	130	165	M10	8
38	KA	114.3	200	M12	8
38	KB	130	215	M10	8
38	KC	130	215	M12	8
38	KD	95	200	M10	18
38	KE	114.3	200	M12	18
38	LA	180	215	M12	8
38	LB	180	215	M12	18
38	MA	180	265	M12	8
38	MB	200	235	M12	8
38	MC	215.9	184.15	13.7	5.5
38	MD	200	250	M8	18
38	NA	230	265	M12	8

28, 19, and 14 Input Bore Mounting Code Tables

Input Bore (mm)	Part# Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
28	FA	80	100	M6	8
28	FB	95	115	M6	8
28	FC	95	115	M8	8
28	FD	95	115	M6	8
28	FE	95	115	M8	6
28	GA	55.563	125.73	M6	8
28	GB	63.5	127	M6	8
28	GC	95	130	M8	8
28	GD	110	130	M8	8
28	GE	110	130	M10	8
28	GF	110	130	8.8	8
28	GG	110	135	M8	8
28	GH	95	135	M8	8
28	HA	110	145	M8	8
28	HB	110	145	M8	18
28	HC	110	145	10.5	8
28	HD	114.3	149.23	10.5	8
28	HE	95	145	M8	18
28	HF	110	145	M8	8
28	JA	110	165	M8	8
28	JB	110	165	M10	8
28	JC	130	165	M10	8
28	JD	130	174	M10	28
28	JE	130	165	M10	18
28	JF	114.3	160	M10	8
28	KA	114.3	200	M12	8
28	KB	130	215	M10	8
28	KD	114.3	200	M12	18
28	KE	150	185	M10	8
28	LA	180	215	M12	8
28	LB	180	220	M12	18
28	MA	200	235	M12	8
28	MB	200	250	M8	18

Input Bore (mm)	Part# Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
19	DA	60	90	M5	6
19	DB	70	90	M5	6
19	DC	70	90	M6	6
19	DD	70	90	M6	16
19	DE	70	90	M5	11
19	EA	73.025	98.43	M5	11
19	EB	80	100	M6	6
19	EC	80	100	M6	16
19	ED	60	98.99	M6	6
19	FA	95	115	M8	6
19	FB	95	115	M8	16
19	GA	55.563	125.73	M6	11
19	GB	95	130	M8	6
19	GC	110	130	M8	11
19	GD	110	130	8.8	6
19	GE	95	130	M8	16
19	GF	100	125	M8	16
19	GH	95	135	M8	11
19	HA	110	145	M8	6
19	HB	110	145	M8	21
19	HC	110	145	10.5	11
19	HD	114.3	149.23	M8	11
19	HE	114.3	149.23	10.5	11
19	JA	130	165	M10	16
19	JB	115	165	M8	21

Input Bore (mm)	Part# Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
14	BA	38.1	66.68	M4	5
14	BB	38.1	66.68	M5	5
14	BC	38.1	66.68	M5	10
14	BD	40	63	M4	5
14	BE	40	63	M5	5
14	BF	40	65	M5	5
14	BG	40	70	M4	5
14	BH	50	60	M4	10
14	BJ	50	70	M4	5
14	BK	50	70	M5	5
14	BL	50	70	M5	15
14	BM	50	70	M5	10
14	BN	50	70	M4	10
14	BP	36	70.71	M4	5
14	CA	60	75	M5	5
14	CB	60	75	M6	10
14	CC	60	80	M4	5
14	DA	50	95	M6	5
14	DB	60	85	M5	5
14	DC	60	90	M5	5
14	DD	70	85	6.5	5
14	DE	70	90	M5	10
14	DF	70	90	M6	5
14	DG	70	90	M6	15
14	DH	70	95	M6	5
14	DJ	60	95	M5	5
14	DK	36.8	82.024	M6	15
14	DL	62	91.924	M5	10
14	EA	50	100	M6	5
14	EB	73.025	98.43	M5	5
14	EC	80	100	M6	5
14	ED	80	100	M6	15
14	EE	73.025	98.43	M6	15
14	EF	50	98.43	M5	5
14	EG	60	98.995	M5	5
14	EH	80	105	M6	15
14	EJ	60	98.995	M6	10
14	EK	73.025	98.43	M6	5
14	EL	73	94	M6	5
14	EM	83	104	M8	10
14	FA	60	115	M6	5
14	FB	95	115	M8	15
14	GA	80	139.7	M6	5
14	GB	80	130	M5	20
14	GC	94	120	M8	10
14	JA	115	165	M8	10

8 and S8 Input Bore Mounting Code Tables

Input Bore (mm)	Part# Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
8	AA	20.02	46.69	M3	5
8	AB	22	43.82	4.7	10
8	AC	22	48	M3	5
8	AD	22.22	50.8	M3	5
8	AE	25.4	38.89	4	10
8	AF	30	45	M3	5
8	AG	30	46	M4	5
8	AH	30	46	M4	10
8	AJ	30	46	3.5	10
8	AK	34	48	M3	10
8	AL	30	48	M3	5
8	AM	22	43.82	3.5	5
8	AN	40	50	M4	5
8	AQ	37.6	48	M3	5
8	BA	38.1	66.68	M4	5
8	BB	38.1	66.68	M5	5
8	BC	50	60	M4	10
8	BD	50	70	M4	5
8	BE	50	70	M5	5
8	BF	50	70	M5	10
8	BG	36	70.71	M4	5
8	BH	54	70	M4	5
8	BJ	50	58	M3	5
8	CA	50	80	M4	10

Input Bore (mm)	Part# Code	Pilot (mm)	BCD (mm)	Tapped Hole	Pilot Depth (mm)
S8	ZA	20.02	46.69	M3	5
S8	ZB	22	43.82	4.7	10
S8	ZC	22	48	M3	5
S8	ZD	22.22	50.8	M3	5
S8	ZE	25.4	38.89	4	10
S8	ZF	30	45	M3	5
S8	ZG	30	46	M4	5
S8	ZH	30	46	M4	10
S8	ZJ	30	46	3.5	10
S8	ZK	34	48	M3	10
S8	ZL	30	48	M3	5
S8	ZM	22	43.82	3.5	5
S8	ZN	40	50	M4	5
S8	ZQ	37.6	48	M3	5
S8	BA	38.1	66.68	M4	5
S8	BB	38.1	66.68	M5	5
S8	BC	50	60	M4	10
S8	BD	50	70	M4	5
S8	BE	50	70	M5	5
S8	BF	50	70	M5	10
S8	BG	36	70.71	M4	5
S8	BH	54	70	M4	5
S8	BJ	50	58	M3	5
